| Main ports (4) | 4 main ports |
|---|---|
| Series (WE) | WE |
| Size (6) | 6 |
| Symbols (J) | J |
| Component Series (6X) | 60 ... 69: unchanged installation and connection dimensions |
| Spring return | With spring return |
| Solenoid (E) | High-power wet-pin solenoid with detachable coil |
| Electrical voltages (G24) | 24V |
| Manual override | Without manual override |
| Corrosion resistance | None (valve housing primed) |
| Electrical connection (K4) | Standard |
|---|---|
| Spool position monitoring (QR0G24S) | Monitored rest position |
| Switching time increase | Without switching time increase |
| Throttle insert | Without throttle insert (standard) |
| Clamping length | 42 mm [1.65 inch] (standard) |
| Control spool play | Standard (recommended) |
| Seal Material (V) | FKM seals |
| Approval | Standard |
| Locating hone | Without locating hole |
| Power consumption | Standard |
